VIEW SPECIFICATIONS

VIEW SPECIFICATIONS Desription
Sign housing type With doors
Sign illumination side Two sided
Sign face dimensions (WxH mm) 400x400
Sign housing dimensions (WxHxD mm) 460x460x165
Sign housing material Stainless steel 316L
Sign housing finish Powder coated RAL
Sign face material Polycarbonate
Sign face sheeting 3M film with digital print
Sign internal illumination LED lightning 100.000h
Power supply 24V DC / AC 50Hz
Power 10 W
Insulation class Class II (Double insulation)
IP protection class IP66
Sign weight 9 kg
Temp range -25°C to +55°C
Certificates CE certification according to EN12899-1:2008
Test reports According to project requests
Wall mounting options Swing - perpendicular
